Driving Live HUD Widgets from Device Events in Verse

What you'll learn

• How to access the live player_ui for each player and attach a widget to it.
• Building a text_block and hosting it inside a canvas for positioning.
• Subscribing to a trigger_device event so gameplay drives your interface.
• Pushing updated values into a widget with SetText so the HUD stays in sync.

How it works

Each player has a player_ui you fetch with GetPlayerUI[Player]. You add widgets to it once with AddWidget, then keep a reference to the widget so you can mutate its properties later. A canvas lets you position widgets in its slots; individual widgets like text_block expose setters such as SetText.

The reactive part comes from Trigger.TriggeredEvent, a listenable(?agent). Subscribing returns a cancelable handle. Inside the callback we bump a counter and immediately call SetText on the stored widget — no per-frame polling, the update happens exactly when the event fires. Note that GetPlayerUI[...] uses square brackets because it is fallible, so it must be called inside an if.

Let's build it

Place a Trigger Device in your level, drop the ui_state_driver device into the scene, assign the trigger to the editable slot, and playtest. Every time the trigger fires, an on-screen counter updates live for every player.

using { /Fortnite.com/Devices }
using { /Fortnite.com/UI }
using { /UnrealEngine.com/Temporary/UI }
using { /Verse.org/Simulation }

# Drives a live HUD text widget from a trigger device event.
ui_state_driver := class<concrete>(creative_device):

    @editable
    Trigger : trigger_device = trigger_device{}

    # The widget whose text we mutate each time the trigger fires.
    Readout : text_block = text_block{}

    # Running count pushed to the HUD.
    var CurrentValue : int = 0

    OnBegin<override>()<suspends>: void =
        # Attach the readout widget to every player's UI once at startup.
        for (Player : GetPlayspace().GetPlayers()):
            if (PlayerUI := GetPlayerUI[Player]):
                # A canvas positions widgets in its slots; add our text into it.
                MyCanvas := canvas:
                    Slots := array:
                        canvas_slot:
                            Widget := Readout
                PlayerUI.AddWidget(MyCanvas)

        # Show an initial value before any events arrive.
        Readout.SetText(StringToMessage("Progress: 0%"))

        # Subscribe so every trigger activation pushes a fresh value to the HUD.
        Trigger.TriggeredEvent.Subscribe(OnTriggered)

    # Runs whenever an agent (or code) fires the trigger.
    OnTriggered(MaybeAgent : ?agent): void =
        set CurrentValue += 1
        Percent := CurrentValue * 10
        # Push the new state straight into the widget the Scene Graph shows.
        Readout.SetText(StringToMessage("Progress: {Percent}%"))
        Print("UI state driven: progress is now {Percent}%")

    # Helper: wrap a string as the `message` type SetText expects.
    StringToMessage<localizes>(Value : string): message = "{Value}"

Try it yourself

• Change CurrentValue * 10 to a different multiplier and watch the readout climb faster or slower.
• Add a second text_block field and update both from OnTriggered to show a label plus a value.
• Call Readout.SetVisibility(...) to hide the widget until the first trigger fires, then reveal it.

Recap

You wired a trigger_device event to a live HUD widget: fetch each player's player_ui with GetPlayerUI[Player], host a text_block inside a canvas, add it with AddWidget, then subscribe to TriggeredEvent and call SetText in the handler. This event-driven loop keeps the interface synchronized with game state without any polling.
