Spawning Dynamic Text Widgets on the Player UI with Verse
Tutorial intermediate compiles

Spawning Dynamic Text Widgets on the Player UI with Verse

Updated intermediate Code verified

What you'll learn

  • How to subscribe to a button device's InteractedWithEvent and receive the interacting agent
  • How to cast an agent to a player and reach their UI with the fallible GetPlayerUI[]
  • How to build a text_block, place it inside a canvas slot, and add it to the player_ui
  • How to drive live text updates from a <suspends> background loop using Sleep and GetRandomFloat

How it works

A custom UI in UEFN belongs to a single player, so we must start from something player-specific. We subscribe to a button_device's InteractedWithEvent, which sends the agent that pressed it. Because agents can be NPCs, we cast to player with player[Agent] inside an if — this is a fallible expression, so it uses [] brackets in a failure context. GetPlayerUI[...] is likewise fallible (it's <decides> and returns a player_ui, failing when the agent has no UI), so we bind it in the same if.

Once we hold a player_ui, we create a text_block widget, wrap it in a canvas (which lets us position widgets in slots), and call PlayerUI.AddWidget(...). A separate <suspends> coroutine, launched from OnBegin, simulates a live data feed with GetRandomFloat and prints each value — the same place you'd later push into a stored widget's text. Everything downstream of OnBegin runs in a suspendable context so Sleep is legal.

Let's build it

using { /UnrealEngine.com/Temporary/UI }
using { /Fortnite.com/Devices }
using { /Verse.org/Simulation }
using { /Verse.org/Random }
using { /Fortnite.com/UI }

# A custom device that adds a live text widget to a player's UI on button press.
floating_text_device := class<concrete>(creative_device):

    # Drag a Button device here in the Details panel.
    @editable
    InteractButton : button_device = button_device{}

    # The message shown in the spawned widget. `message` (localizable text) is what widgets display.
    Message<localizes> : message = "Floating Text!"

    # Entry point. Runs when the game starts.
    OnBegin<override>()<suspends> : void =
        # Fire our handler each time an agent interacts with the button.
        InteractButton.InteractedWithEvent.Subscribe(HandleInteraction)
        # Kick off a background loop simulating a live data stream.
        DynamicUpdates()

    # A custom UI belongs to one player, so cast the agent and resolve their UI.
    HandleInteraction(Source : agent) : void =
        # player[Agent] and GetPlayerUI[...] are both fallible — bind them in the if condition.
        if (InPlayer := player[Source], PlayerUI := GetPlayerUI[InPlayer]):
            # Build the text widget from our localized message.
            TextWidget : text_block = text_block{ DefaultText := Message }
            # Wrap it in a canvas slot so it can be positioned as UI grows.
            Container : canvas = canvas{}
            Container.AddWidget(canvas_slot{ Widget := TextWidget })
            # Attach the canvas to this player's UI layer — the text now shows on screen.
            PlayerUI.AddWidget(Container)

    # Background coroutine: simulates streaming values you could bind to a widget.
    DynamicUpdates()<suspends> : void =
        loop:
            Sleep(1.0)
            RandVal := GetRandomFloat(0.0, 100.0)
            Print("Simulated dynamic value: {RandVal}")

Try it yourself

  1. Place the floating_text_device in your level and drop a Button device nearby.
  2. In the device's Details panel, assign the Button to Interact Button.
  3. Build Verse Scripts, then playtest and press the button — the text appears in the upper-left of the screen.
  4. Edit Message in the Details panel to change the displayed text, or extend DynamicUpdates to store a text_block reference and refresh it live.

Recap

You wired a button's InteractedWithEvent to a handler, safely cast the interacting agent to a player, and used the fallible GetPlayerUI[] to reach the UI layer. From there you built a text_block, placed it inside a canvas slot, and attached it with AddWidget. Because UI is per-player, always start from a player-specific event and treat player/UI resolution as fallible. Swap the message and background loop for damage numbers, loot popups, or live stats to scale the pattern.
