Toggle Rig State and Show Live HUD Feedback in Verse

What you'll learn

• How to structure a creative_device that reacts to a button_device press.
• Safely flipping a logic state variable using Verse's fallible branching patterns.
• Using GetPlayerUI[], AddWidget, and text_block.SetText to push a live status label to every player's screen.

How it works

We track the rig mode in a mutable var IsIKActive : logic. A logic value is itself fallible, so we never modify it bare — we branch on if (IsIKActive?): and use set to write the opposite value.

The interesting part is the UI. GetPlayerUI[Player] is a <decides> function (note the [] brackets): it must be called inside a failure context because it fails when a player has no UI. We therefore call it inside if (UI := GetPlayerUI[Player]):. Once we hold the player_ui, we call AddWidget(Widget) to render our widget, and SetText(...) on a text_block to display the current mode.

Because AddWidget shows something on screen (a side effect that can't be rolled back), we create ONE text_block per player and reuse it — calling SetText on each toggle rather than adding a fresh widget every press. We loop over GetPlayspace().GetPlayers() so every connected client stays in sync.

Let's build it

Place a button_device in your level, then drop this device in and assign the button to the ToggleButton field in the Details panel.

using { /Fortnite.com/Devices }
using { /Fortnite.com/UI }
using { /Verse.org/Simulation }
using { /UnrealEngine.com/Temporary/UI }

# Toggles a modeled IK/FK rig state and shows it live on every player's HUD.
ik_fk_toggle_device := class<concrete>(creative_device):

    # Assign a placed button_device in the UEFN Details panel.
    @editable ToggleButton : button_device = button_device{}

    # true = IK (Inverse Kinematics), false = FK (Forward Kinematics).
    var IsIKActive : logic := false

    # One reusable text_block per player, keyed by the player.
    var StatusLabels : [player]text_block = map{}

    OnBegin<override>()<suspends>: void =
        # Device events do NOT need () before .Subscribe.
        ToggleButton.InteractedWithEvent.Subscribe(OnRigToggle)
        Print("IK/FK Rig System Initialized (FK by default)")

    # Runs when a player presses the button.
    OnRigToggle(Agent : agent): void =
        # A logic var is fallible: branch on its truth, then set the opposite.
        if (IsIKActive?):
            set IsIKActive = false
        else:
            set IsIKActive = true

        # Build the status message from the new state.
        StatusText := if (IsIKActive?) then "RIG MODE: IK" else "RIG MODE: FK"
        Print("Rig toggled -> {StatusText}")

        # Push the update to every connected player's HUD.
        for (Player : GetPlayspace().GetPlayers()):
            ShowStatus(Player, StatusText)

    # Adds the widget once per player, then reuses it via SetText.
    ShowStatus(Player : player, Text : string): void =
        # GetPlayerUI is <decides> — call with [] inside a failure context.
        if (UI := GetPlayerUI[Player]):
            Label := GetOrCreateLabel(Player, UI)
            Label.SetText(StringToMessage(Text))

    # Returns the player's cached text_block, creating + adding it if needed.
    GetOrCreateLabel(Player : player, UI : player_ui): text_block =
        if (Existing := StatusLabels[Player]):
            Existing
        else:
            NewLabel := text_block{}
            UI.AddWidget(NewLabel)
            if (set StatusLabels[Player] = NewLabel) {}
            NewLabel

    # Wraps a string into a message for SetText.
    StringToMessage<localizes>(Value : string): message = "{Value}"```

> Note: `SetText` takes a `message`, so `StringToMessage` here stands for wrapping your string in a localizable message before display. Declare it as `StringToMessage<localizes>(S:string):message = "{S}"` at file scope if your project doesn't already provide a helper.

## Try it yourself
1. Place your `ik_fk_toggle_device` and a `button_device` in the scene.
2. Assign the button to the `ToggleButton` field in the Details panel.
3. Press the button in-game — the HUD label flips between `RIG MODE: IK` and `RIG MODE: FK`.
4. Extend `OnRigToggle` to also drive real animation (e.g. enable/disable a `vfx_spawner_device`) alongside the label.

## Recap
- Toggle a `logic` with `if (Val?): set Val = false else: set Val = true` — never write a bare `logic`.
- `GetPlayerUI[]` is `<decides>`: call it with `[]` inside an `if`/`for` failure context.
- `AddWidget` renders a widget and is an unrollbackable side effect — add once, then reuse via `SetText`.
- Cache widgets in a `[player]text_block` map so each client keeps a single, updatable label.
- Iterate `GetPlayspace().GetPlayers()` to keep every connected player's HUD in sync.
