The Drivable Mini-Experience

The capstone for Scene Graph: Car Primitive. Everything you earned, on one timeline: a primitive you found by tag, a paint swap, a first-person view on entry, and now — actual driving, under the player's own input.

The whole loop

<!-- section-art:the-whole-loop -->

The Driving Loop

• Part 1 the car is a tagged creative_prop we move with MoveTo.
• Part 2 SetMaterial swaps its paint.
• Part 3 a mutator_zone_device seats the driver and a first-person camera snaps in.
• here Input Trigger devices (throttle + steering) move the car while seated, plus a paint-cycle key.

Driving a prop = moving it yourself

Our car has no engine sim, so we are the engine. While a driver is seated, a coroutine ticks ~16 times a second; each tick reads which controls are held and nudges the car:

DriveLoop(Agent : agent)<suspends> : void =
    loop:
        if (not Driving?):
            break
        MoveTaggedCar(Agent)
        Sleep(0.06)

DriveLoop is launched with spawn the moment the driver enters, and it breaks itself the moment Driving goes false (on exit). Sleep(0.06) paces it. This is the same spawn + <suspends> + Sleep pattern behind every timed system in Verse — here it's a control loop instead of a show.

Reading held input

The step reads each Input Trigger's IsHeld[Agent] — a failable query that succeeds while that player holds the key — and builds the next transform:

StepCar(Agent : agent, Body : creative_prop)<suspends> : void =
    Current : transform = Body.GetTransform()
    var NextRot : rotation = Current.Rotation
    if (SteerLeft.IsHeld[Agent]):
        set NextRot = NextRot.ApplyWorldRotationZ(-TurnRadians)
    if (SteerRight.IsHeld[Agent]):
        set NextRot = NextRot.ApplyWorldRotationZ(TurnRadians)
    var NextPos : vector3 = Current.Translation
    if (Throttle.IsHeld[Agent]):
        Forward : vector3 = NextRot.GetLocalForward()
        set NextPos = Current.Translation + Forward * Speed
    Body.MoveTo(NextPos, NextRot, 0.06)

Steering rotates the car about its up axis (ApplyWorldRotationZ); throttle advances it along the newly-rotated forward, so turning while accelerating curves the path. MoveTo over the same 0.06s as the tick keeps motion smooth.

Seating and releasing

On enter we guard against double-seating, push first person, register every control, flip Driving true, and launch the loop. On exit we undo all of it:

OnSeat(Agent : agent) : void =
    if (not Driving?):
        DriverCamera.AddTo(Agent)
        Throttle.Register(Agent)
        SteerLeft.Register(Agent)
        SteerRight.Register(Agent)
        PaintInput.Register(Agent)
        set Driving = true
        spawn { DriveLoop(Agent) }

The if (not Driving?) re-entry guard means a second player wandering into the zone can't hijack a car that's already being driven.

The full device

This capstone is compile-verified in UEFN 5.8 (0 errors). Tag the car body car_body_tag; wire a Mutator Zone, a First-Person Gameplay Camera, three Input Triggers (throttle / steer-left / steer-right), a paint Input Trigger, and two paint materials. Walk into the zone and drive.

What you built

<!-- section-art:what-you-built -->

Barrel Drift

A genuinely drivable experience from compile-clean, fully-public Verse — find a prop, paint it, seat a driver in first person, and steer it under live input. You also learned the honest boundaries: no creator-built wheeled vehicles, no per-parameter material colour, no custom input actions — and the public tool that stands in for each.

Recap

• The car is a prop, so the drive loop is yours: a spawned <suspends> loop that ticks while Driving?.
• input_trigger_device.IsHeld[Agent] is a failable per-tick read of held controls.
• ApplyWorldRotationZ steers; GetLocalForward + throttle drives along the new facing.
• A var Driving re-entry guard stops a second player hijacking the car.
• The domain's honest boundaries: internal vehicle sim, internal material params, internal input authoring — each met with a public stand-in.
