capture_area_device: Control Points, Flags, and Zone Logic

Overview

The capture_area_device defines a cylindrical volume on your island. At its simplest it fires AgentEntersEvent / AgentExitsEvent so you can use it as a fancy trigger zone — great for automatic doors, proximity traps, or safe-zone enforcement. Turn on Capture mode in the Details panel and it becomes a full control point: teams contest it, a progress bar fills, control changes hands, and AreaIsScoredEvent fires on every periodic tick while a team holds it.

Reach for it when you need:

• A domination / king-of-the-hill control point
• A flag delivery zone (pair with capture_item_spawner_device)
• A proximity trigger that knows how many players are inside (GetAgentsInVolume)
• A zone you can resize at runtime (SetRadius, SetHeight) or lock/unlock mid-game (DisallowCapture / AllowCapture)
• An objective pulse that draws players to the zone (ActivateObjectivePulse)

API Reference

capture_area_device

Used to create a zone that can trigger effects once players enter it. Can be set up to be capturable by a team, to provide a score while held, or to require a specific item as a drop-off.

Full public surface, resolved verbatim from the live Epic digest (Fortnite.digest.verse).

capture_area_device<public> := class<concrete><final>(creative_device_base):

Events (subscribe a handler to react):

Methods (call these to make the device act):

Walkthrough

Scenario — Three-Point Domination

You have three capture areas (A, B, C) on a map. A Verse device manages all three:

• When a point is first entered it pulses its objective marker so enemies know it's being contested.
• When control changes it prints a message and removes the pulse.
• When the last player leaves it neutralizes the point so neither team holds it passively.
• A helper method lets a designer resize any point at runtime (e.g., shrink it during a final round).

using { /Fortnite.com/Devices }
using { /Verse.org/Simulation }
using { /UnrealEngine.com/Temporary/Diagnostics }

# Localized message helper
PointCapturedMsg<localizes>(PointName : string) : message = "Point {PointName} has been captured!"
PointContestedMsg<localizes>(PointName : string) : message = "Point {PointName} is being contested!"
PointNeutralizedMsg<localizes>() : message = "A point has been neutralized!"

domination_manager := class(creative_device):

    # Wire these to your three placed Capture Area devices in the Details panel
    @editable
    CaptureAreaA : capture_area_device = capture_area_device{}

    @editable
    CaptureAreaB : capture_area_device = capture_area_device{}

    @editable
    CaptureAreaC : capture_area_device = capture_area_device{}

    # Called once at game start — subscribe to all relevant events
    OnBegin<override>()<suspends> : void =
        # Point A
        CaptureAreaA.FirstAgentEntersEvent.Subscribe(OnFirstEntersA)
        CaptureAreaA.ControlChangeEvent.Subscribe(OnControlChangedA)
        CaptureAreaA.LastAgentExitsEvent.Subscribe(OnLastExitsA)
        CaptureAreaA.AreaIsContestedEvent.Subscribe(OnContestedA)

        # Point B
        CaptureAreaB.FirstAgentEntersEvent.Subscribe(OnFirstEntersB)
        CaptureAreaB.ControlChangeEvent.Subscribe(OnControlChangedB)
        CaptureAreaB.LastAgentExitsEvent.Subscribe(OnLastExitsB)

        # Point C
        CaptureAreaC.FirstAgentEntersEvent.Subscribe(OnFirstEntersC)
        CaptureAreaC.ControlChangeEvent.Subscribe(OnControlChangedC)
        CaptureAreaC.LastAgentExitsEvent.Subscribe(OnLastExitsC)

        # Activate objective pulses at game start so players know where the points are
        CaptureAreaA.ActivateObjectivePulse()
        CaptureAreaB.ActivateObjectivePulse()
        CaptureAreaC.ActivateObjectivePulse()

    # ── Point A handlers ──────────────────────────────────────────────────────

    OnFirstEntersA(Agent : agent) : void =
        # Someone just walked in — pulse so enemies see it's being contested
        CaptureAreaA.ActivateObjectivePulse()

    OnControlChangedA(Agent : agent) : void =
        # A team now owns the point — stop pulsing, it's captured
        CaptureAreaA.DeactivateObjectivePulse()

    OnLastExitsA(Agent : agent) : void =
        # Nobody left inside — neutralize so it doesn't stay owned passively
        CaptureAreaA.Neutralize()
        CaptureAreaA.ActivateObjectivePulse()   # pulse again so players come back

    OnContestedA(Agent : agent) : void =
        # Optionally re-pulse when contested (enemy entered an owned point)
        CaptureAreaA.ActivateObjectivePulse()

    # ── Point B handlers ──────────────────────────────────────────────────────

    OnFirstEntersB(Agent : agent) : void =
        CaptureAreaB.ActivateObjectivePulse()

    OnControlChangedB(Agent : agent) : void =
        CaptureAreaB.DeactivateObjectivePulse()

    OnLastExitsB(Agent : agent) : void =
        CaptureAreaB.Neutralize()
        CaptureAreaB.ActivateObjectivePulse()

    # ── Point C handlers ──────────────────────────────────────────────────────

    OnFirstEntersC(Agent : agent) : void =
        CaptureAreaC.ActivateObjectivePulse()

    OnControlChangedC(Agent : agent) : void =
        CaptureAreaC.DeactivateObjectivePulse()

    OnLastExitsC(Agent : agent) : void =
        CaptureAreaC.Neutralize()
        CaptureAreaC.ActivateObjectivePulse()

    # ── Designer helper — call from another device or a timer ─────────────────
    # Shrinks all three points to create a tighter final-round zone
    ShrinkAllPoints() : void =
        CaptureAreaA.SetRadius(3.0)
        CaptureAreaA.SetHeight(2.0)
        CaptureAreaB.SetRadius(3.0)
        CaptureAreaB.SetHeight(2.0)
        CaptureAreaC.SetRadius(3.0)
        CaptureAreaC.SetHeight(2.0)

Line-by-line highlights:

Common patterns

Pattern 1 — Automatic Proximity Door

Use FirstAgentEntersEvent / LastAgentExitsEvent to open and close a door. The capture area sits in the doorway; no capture settings needed.

using { /Fortnite.com/Devices }
using { /Verse.org/Simulation }

auto_door_device := class(creative_device):

    @editable
    DoorZone : capture_area_device = capture_area_device{}

    # A mutator zone or prop manipulator would be the real door;
    # here we use a second capture area as a stand-in for illustration.
    @editable
    InnerDoorZone : capture_area_device = capture_area_device{}

    OnBegin<override>()<suspends> : void =
        # Disable capture so this zone is purely a proximity sensor
        DoorZone.DisallowCapture()

        DoorZone.FirstAgentEntersEvent.Subscribe(OnSomeonePproaches)
        DoorZone.LastAgentExitsEvent.Subscribe(OnEveryoneLeaves)

    OnSomeonePproaches(Agent : agent) : void =
        # "Open" the door — enable the inner zone or trigger your door prop
        InnerDoorZone.Enable()

    OnEveryoneLeaves(Agent : agent) : void =
        # "Close" the door after the last person leaves
        InnerDoorZone.Disable()

Key calls: DisallowCapture() turns off the scoring system so the zone is a pure sensor. Enable() / Disable() on a second device acts as the door actuator.

Pattern 2 — Head-Count Gate (IsInArea + GetAgentsInVolume)

Only unlock a vault when three or more players are standing in the zone simultaneously — a co-op puzzle mechanic.

using { /Fortnite.com/Devices }
using { /Verse.org/Simulation }

vault_gate_device := class(creative_device):

    @editable
    PressurePlate : capture_area_device = capture_area_device{}

    @editable
    VaultDoor : capture_area_device = capture_area_device{}

    # Minimum players required to open the vault
    RequiredPlayers : int = 3

    OnBegin<override>()<suspends> : void =
        PressurePlate.DisallowCapture()
        VaultDoor.Disable()   # vault starts locked

        # Check the count every time someone enters or exits
        PressurePlate.AgentEntersEvent.Subscribe(OnZoneChanged)
        PressurePlate.AgentExitsEvent.Subscribe(OnZoneChanged)

    OnZoneChanged(Agent : agent) : void =
        Agents := PressurePlate.GetAgentsInVolume()
        if (Agents.Length >= RequiredPlayers):
            VaultDoor.Enable()    # enough players — open the vault
        else:
            VaultDoor.Disable()   # too few — keep it locked

Key calls: GetAgentsInVolume() returns the live slice of agents inside right now. AgentEntersEvent and AgentExitsEvent (not just First/Last) fire for every individual, so the count is always fresh.

Pattern 3 — Neutralize Event + GiveControl (Flag Delivery)

When a flag carrier delivers an item, immediately give control to their team and then neutralize after a delay — simulating a timed capture in a CTF variant.

using { /Fortnite.com/Devices }
using { /Verse.org/Simulation }

ctf_delivery_zone := class(creative_device):

    @editable
    DeliveryZone : capture_area_device = capture_area_device{}

    OnBegin<override>()<suspends> : void =
        DeliveryZone.ItemIsDeliveredEvent.Subscribe(OnFlagDelivered)
        DeliveryZone.NeutralizeEvent.Subscribe(OnZoneNeutralized)

    OnFlagDelivered(Agent : agent) : void =
        # Hand control to the delivering agent's team immediately
        DeliveryZone.GiveControl(Agent)
        # Wait 10 seconds, then reset the zone for the next round
        Sleep(10.0)
        DeliveryZone.Neutralize()

    # NeutralizeEvent sends ?agent — must unwrap the option
    OnZoneNeutralized(MaybeAgent : ?agent) : void =
        if (A := MaybeAgent?):
            # A specific agent triggered the neutralize
            DeliveryZone.ActivateObjectivePulse()
        else:
            # Neutralized programmatically (no agent responsible)
            DeliveryZone.ActivateObjectivePulse()

Key calls: ItemIsDeliveredEvent fires when a player drops a tracked item (flag) into the zone. GiveControl(Agent) skips the capture progress bar and instantly awards the point. NeutralizeEvent sends ?agent — always unwrap with if (A := MaybeAgent?).

Gotchas

1. NeutralizeEvent sends ?agent, not agent

Every other event on this device sends a plain agent. NeutralizeEvent sends ?agent (optional) because the neutralize can be triggered programmatically with no player involved. Always unwrap:

OnNeutralized(MaybeAgent : ?agent) : void =
    if (A := MaybeAgent?):
        # use A as a real agent

Forgetting this causes a type mismatch compile error.

2. @editable is mandatory for placed devices

You cannot write MyArea := capture_area_device{} and expect it to refer to the device you placed in the level. That creates a new, unplaced instance. Every device you want to control from Verse must be declared as an @editable field and then dragged into the slot in the UEFN Details panel.

3. DisallowCapture() before using as a pure sensor

If you use a capture area purely as a proximity trigger (door, head-count gate, etc.) and leave Capture enabled in the Details panel, the zone will still run its scoring logic, fire ControlChangeEvent, and potentially award score. Call DisallowCapture() in OnBegin to suppress all of that.

4. IsInArea has <transacts><decides> effects

IsInArea is a failable expression — it only succeeds if the agent is inside. You must call it inside an if (or another decision context):

# Correct
if (DeliveryZone.IsInArea[SomeAgent]):
    # agent is confirmed inside

Calling it outside a decision context is a compile error.

5. SetRadius / SetHeight take float, not int

Verse does not auto-convert integers to floats. Write SetRadius(5.0) not SetRadius(5) — the latter is a type error.

6. Objective pulse state is not automatically reset

ActivateObjectivePulse() and DeactivateObjectivePulse() are fire-and-forget toggles. If you Disable() the device and then Enable() it again, the pulse state is whatever you last set it to. Re-activate or deactivate explicitly after re-enabling.

7. GiveControl bypasses the capture progress bar

This is intentional for scripted scenarios (flag delivery, designer-triggered events), but if you call it mid-contest the progress bar will snap immediately. Pair it with ControlChangeStartsEvent if you need to animate a transition in your UI.
